ATS-T480R Heavy-Duty Mini Skid Steer Loader

SKU
Sold out
$5,900.00 - $5,900.00
$5,900.00
$5,900.00 - $5,900.00
$5,900.00
Availability:
Out of stock

✓ 25HP RATO760 Power. Built for More.

✓ More Weight. More Stability.

✓ Heavy-Duty Tracks. Stay on Track.

✓ 250W Cooling. Work Longer.

Free Shipping

We proudly offer Free Shipping & Free Unloading to the lower 48 states (excluding Alaska, Hawaii, and Puerto Rico) with fast fulfillment from our U.S. warehouses located in California, Texas, Georgia, West Virginia, New Jersey, and Illinois.

Warranty & Technical Support

We stand behind every product with a 1-year warranty and lifetime customer support. From technical guidance to replacement parts, our team is here to support you throughout the life of your equipment. Frequently needed parts are stocked in our U.S. warehouses for quick and convenient delivery.

Return & Refund Policy

For more information on our returns, refunds, and warranty policies, please review our full Return & Refund Policy

🔧Features

skid_steer_atspower_T480R_front_bucket_outdoor_view
skid_steer_atspower_T480R_rear_side_angle_shot
skid_steer_atspower_T480R_side_profile_lawn_scene
skid_steer_atspower_T480R_real_part_detail_collage
skid_steer_atspower_T480R_spec_sheet_parameter_table

⚙️ Specifications

·Operating weight of the completemachine: 2755.8 Ibs
·Walking speed: 4.7 km/h
·Maximumlifing capacity: 838 Ibs
·MaximumPin Height: 67 in
·Maximum Dump Height: 57 in
·Bucket dump angle: 90
·Wheelbase H: 28.7 in
·Engine model: RATO760
·Displacement: 764 CC
·Oilvolume: 1.6 L
·Power: 20.5 KW/3600 rpm
·Hydraulic oil capacity: 24 L
·Gasoline tank capacity: 18 L
·Main pump type/model: gear pump/8+8
·Maximumflowrateofmainpump: 28.8 L/min
·Multi-wayvalve: 3+2
·Travelinghydraulicmotor: BMER-305
·Tensioning form: mechanical
·Overalldimensions: 93x41x53 in
